• Hytrol-Model “CCEZ” Case Conveyor (Air)



  The model CCEZ is a horizontal plastic belt conveyor designed for accumulating 12 & 24 packs of canned beverages where high speeds and large through-puts are required. Shown with optional floor supports.

  • Bed: 13" deep x 1-1/2" flange x 12 ga. formed, powder painted steel frame.
  • Belt: 6" wide x 1/2" thick low friction plastic belt (4-1/2" wide available).
  • Motor: 1 HP 230/460/3 EE with AC variable speed controller.
  • Adjustable floor supports available.
  • Accumulation zones: 24" long air controlled.
  • EZLogic accumulation module located in each zone.

• Model “C” – Cleated Incline (Hytrol – Incline Belt Conveyor, Cleated)



  The model C handles bags, boxes, cartons, and parts. It may be set at any angle from horizontal to 45º for various uses, including floor-to-floor conveying and the transportation of materials from building to truck or box car. Shown with optional floor supports.

  • Bed: 6-5/8" deep x 12 ga. formed bed, powder painted. Standard sections come in lengths of 6', 8', & 10'.
  • Belt: hardwood cleats spaced every 60". Conveyor can be supplied less cleats.
  • Belt widths: 14", 18", 24", & 30".
  • Motor: energy efficient motor with brake.
  • Adjustable floor supports available.
  • Capacity: up to 520 lbs.
  • Reversible.

• Hytrol – Model “TL” Heavy Duty Slider Bed Belt Conveyor



  The model TL with its rugged, heavy-duty construction, is ideally used for long assembly line operations, inspections, testing, sorting, and packing. Conveyor can be floor supported or ceiling hung. Shown with optional floor supports.

  • Bed: 6-5/8" deep x 12 ga. formed powder painted.
  • Belt widths: 24", 30", 36", 42", & 48".
  • End drive (standard).
  • Motor: 1 HP standard, 2 HP max.
  • Adjustable floor supports available.
  • Capacity (maximum load per linear foot of conveyor): 100 lbs., not to exceed rated capacities.
  • Reversible (with center drive).
  • 24-hour stockyard availability (contact for sizes available).

• TS-1500-100 & TS-1500-140 Belt Curve



  The TS1500-100 is available with belt widths: 10", 12", 14", 16", and 18".

  The TS1500-140 is available with belt widths: 20", 22", 24", 26", 28", 30", 32", 34", 36", 38", 40", 42", 44", 46", and 48".

  Both models TS1500-100 and TS1500-140 provide a positive flow of product by means of a belt, driven by tapered pulleys. Conveyor is versatile in that it can transport a wide variety of products. Available in 45º, 60º, 90º, and 180º turns. Shown with optional floor supports.

  • Transnorm - TS-1500-140 Belt Curve
  • Bed: 8-3/8" inside, 10-1/2" outside; 2" x 2" x 3/16" structural steel all welded construction.
  • Belt: black monofilament, PVC top with urethane guide strip.
  • Motor: 3/4 HP shaft mounted right angle gear motor standard, 5 HP max.
  • Adjustable floor supports available.
